Qotom Q310p 3215u 8GB 256GB SSD Mini PC COM Serial Port IPC POS Computer RS-232
Qotom Q310p 3215u 8GB 256GB SSD Mini PC COM Serial Port IPC POS Computer RS-232
Regular price
$115.99 USD
Regular price
Sale price
$115.99 USD
Unit price
per
Shipping calculated at checkout.
Qotom Q310p 3215u 8GB RAM 256GB SSD Mini PC COM Serial Port IPC POS Computer RS-232
NO OS,come with
compatible adapter show in photoBasic Info.
Model NO.
Q310P-S050003
Memory Capacity
8GB
CPU
Intel Celeron
HDD Capacity
256GB
GPU
Intel
Memory Type
DDR3l
Use
Commercial
CPU Frequency
1.7GHz
Brand Name
Qotom
Integrated Graphics
Intel HD Graphics
Main Port
2 HDMI+2 LAN+2 USB2.0+4 USB3.0+6 COM
Memory
Support DDR3l RAM
Storage
Support Msata SSD
Hard Drive
Support 2.5-Inch SATA HDD
System
Support Windows/Pfsense/Linux, etc.
Support WiFi
Yes
Watch Dog
Yes
AES-Ni
No
Transport Package
261 X 220 X 80mm
Specification
187 x 111 x 50mm
Origin
China
HS Code
8471494000
Product Description
| Processor System | Expansion | |||
| CPU | Intel Celeron Broadwell SOC Processor Default 3215U Dual Core Processor, 1.5GHz, 2M Cache |
mSATA | 1xFull Size Mini-PCIe for SSD | |
| CPU TDP | 15W | Mini-PCIe | 1 x Mini-PCIe for Option, 1, Full-length for 3G, Half-length for Wi-Fi Module by Default |
|
| Memory | 1xDDR3L SO-DIMM Socket (Up to 8G, 1333/1600MHz) | SIM Card Slot | 1 | |
| Chipset | By CPU | Automatically Boot Jumper | 1 | |
| Graphics | Intel® HD Graphics | VGA | 1x2.0 Pitch Header | |
| LAN Chipset | 2xIntel I211-AT Gigabit LAN | GPIO | 1x2.0 Pitch Header | |
| Audio | Realtek ALC662 HD Audio | RS-485 | COM2 can be set up as RS-232/RS-485 (Factory Setting) | |
| Watch Dog | Yes | DC-in | Header | |
| Front I/O | Power Requirement | |||
| Power Button | 1 | Power Adapter | 12V3A | |
| LED | 1xPower LED, 1 x HDD LED | DC Jack | 5.5mm, 2.5mm | |
| USB | 2xUSB 3.0, 2xUSB 2.0 | |||
| Serial Port | 2 x RS-232 (COM5, COM6) | Environmental | ||
| Operating Temp | 0°C~50° C | |||
| Rear I/O | Non-Operating Temp | -20°C~80° C | ||
| Power | 1xDC Jack | Humidity | 10%~90% | |
| Video Output | 2xHDMI, 1 x VGA (Optional) | |||
| USB | 2xUSB 3.0 | Mechanical | ||
| LAN | 2xRJ45 Port for Gigabit LAN | Material | Aluminum | |
| Audio | 1 (Mic-in, Line-out) | Dimension | 187x111x50mm | |
| Serial Port | 4 x RS-232 (COM1, COM2, COM3, COM4) | Weight | 1.1kg | |
| Storage | Mounting | VESA Mounting Bracket | ||
| Type | 1x2.5-inch HDD/SSD 1xMini-PCIe for mSATA SSD |
Packaging Dimension | 261x218x75mm | |
| Kensington Lock | Support | |||
| OS Support | Cooling Mode | Fanless Design | ||
| OS | Windows 7, Windows 8, Windows 10, Linux |
Packing Included
1 x Mini PC
1 x Power Supply
2 x Antennas
1 x Mini PC
1 x Power Supply
2 x Antennas
